USB 16 Channel Relay Module,Board for Home Automation - 24V
4.9 (22 items)
Limited Time SaleUS$54.00 cheaper than the new price!!
Free cash-on-delivery fees for purchases over $99
Product details
| Management number | 210254168 | Release Date | 2026/04/02 | List Price | US$36.00 | Model Number | 210254168 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
Description: This is relay board with 16 SPDT Relays controlled via PC USB port and it is shown as virtual serial port (virtual com port). It uses one USB port of your PC and it is controlled via serial RS232 commands. There is flexible software for this usb relay module allowing to be designed simple automation project or control from command line. You can control electrical devices, water jets, motors and so on. Easy to integrate in small home automation and robotics projects. Specifications: *FT232RL optical isolation against communication noises *Communication: serial USB communication (Virtual Com Port) *Led-s: Relay Led, Power ON Led, USB ON Led, Rx Led, Tx Led *PCB parameters: FR4 / 1.5mm / two layers / metalized holes / HAL / white stamp / solder mask *Extra PCB openings for better voltage isolation *Doubled high current tracks *Size: W=82mm x L=203mm x H=24mm *Operating temperature range: from -30 ºC to +80 ºC *Supported by DRM software (Windows 32/64 and Linux 32) *Supported by Denkovi Command line tool (Windows 32/64 and Linux 32) *Software examples: VB6, BCB6, Java, .NET 2010 Express, LabVIEW. Please contact with us for download. Documentation: http://denkovi.com/Documents/USB-Relay-16Channels-v3/UserManual.pdf Application examples: *Christmas lights *Home irrigration systems *Home automation *Create week/day timers *Open doors and windows via PC *Aquariums applications
- 16 x SPDT Relays 10A / 250VAC, 15A / 120VAC, 10A / 28VDC
- Software examples: VB6, BCB6, Java, .NET, Labview, Python
- Android software available
- Converter chipset: FT232RL
- Power supply requirements: 24V DC / 400mA
| Model | DAE-CB/Ro16-RAS2415-USB |
|---|---|
| Wattage | 9.6 watts |
| Brand Name | Denkovi Assembly Electronics Ltd |
| Item Weight | 0.01 Ounces |
| Part Number | DAE-CB/Ro16-24V-USB-PCB |
| Coil Voltage | 24 Volts |
| Contact Type | Spdt |
| Manufacturer | Denkovi Assembly Electronics Ltd |
| Mounting Type | PCB Mount |
| Connector Type | Usb |
| Current Rating | 10 Amps, 15 Amps |
| Operation Mode | Automatic |
| Contact Material | Silver |
| Contact Current Rating | 10 Amps |
| Maximum Switching Voltage | 24 Volts |
