Baumer BVF2 4" (100 mm) SS Pressure Gauge with SS 304 Body Bourdon Tube for Industries, Compressors (Range: 0 to -760mm. Hg.)

Baumer BVF2 4" (100 mm) SS Pressure Gauge with SS 304 Body with Features: CE & Apex Approved electrical contacts | Stainless Steel case & measuring system | Filled version available | Standard followed in general EN 837-1.Application are as To control the electrical operation of compressors , pumps, Motors, Presses, Hydraulic, Pneumatic equipments, Chemicals, Petrochemical plants, etc.

• Standard Version: 100 mm| Accuracy: ±1.6% of F. S. | Ambient temperature: -4 °F to 140°F (-20°C to + 65°C) | Process temperature: Max. (Max. 356°F/ 180°C) | Operating pressure range: 75% of Scale Value| Over pressure limit: ≤100 bar-125% of Max. Scale Value; > 100 to ≤600 bar- 115% of Max. Scale Value
• Case & Bezel: AISI 304 SS (Bayonet Type) | Bourdon: AISI 316L SS | Socket: AISI 316 SS| Movement: AISI 304 SS| Joints: Tig Argon Arc Welding
• Dial: Aluminium, black graduation on white background| Pointer: Aluminium, black coloured, slotted Zero adjustable| Window: Sheet Glass| Filling Plug: Neoprene| Gasket: Neoprene| Protection: IP 65|
• Dry but fillable version - Fillable Dampening Liquid: Glycerine 99.7%| Process Temperature: Maximum 149°F / 65°C| Window: PlexiGlass | Glycerine filled version - Accuracy: ±1.6% of F. S.| Ambient Temperature: Maximum 149°F / 65°C| Process Temperature: Maximum 149°F/ 65°C| Window: PlexiGlass| Dampening Liquids: Glycerine 99.7%
• Supply scope: 1 unit of Baummer BVF2 4” SS pressure gauge with instruction manual | Applications: Suitable for clean air & gaseous or liquid media that will not obstruct the pressure system.
